Preheated activation type electronic ballast-T5 series-single lamp
Click image to view full sizeItem-Name:
Preheated activation type electronic ballast-T5 series-single lamp
Preheated activation type electronic ballast-T5 series-single lamp
More-Details:
Hole diameter：300mm
T5 single lamp series（T5 light tube suitable）
Model | Input Voltage(V) | Input Current(A) | Input Power(W) | Lamp Current(A) | Power Factor(%) | Lamps Type(W) |
BM-UT50351 | 110 / 220 | 0.38 ~ 0.08 | 18 / 25 / 34 / 42 | 0.17 | 98 | T5 14 / 21 / 28 / 35 |
BM-UT50391 | 110 / 220 | 0.39 ~ 0.12 | 26 / 42 | 0.3 | 99 | T5 24 / 39 |
BM-UT50541 | 110 / 220 | 0.55 ~ 0.28 | 61 | 0.44 | 99 | T5 54 |
BM-CT50351 | 277 | 0.09 / 0.12 / 0.14 | 24 / 32 / 40 | 0.17 | 98 | T5 21 / 28 / 35 |
BM-CT50541 | 277 | 0.21 | 58 | 0.44 | 99 | T5 54 |
Certified with CNS 13755 and registered for authentication by Bureau of Standards, Metrology and Inspection ,MOEA. CNS 14115 EMI specification compliant.
