Preheated activation type electronic ballast-FL/T8 series-single lamp
Click image to view full sizeItem-Name:
Preheated activation type electronic ballast-FL/T8 series-single lamp
Preheated activation type electronic ballast-FL/T8 series-single lamp
More-Details:
Hole diameter：300mm
FL series（T8/T9 light tube suitable）
Model | Input Voltage(V) | Input Current(A) | Input Power(W) | Lamp Current(A) | Power Factor(%) | Lamps Type(W) |
BM-UFL0321 | 110 / 220 | 0.35 ~ 0.175 | 38 | 0.26 | 99 | T8 32 |
BM-UFL0401A | 110 / 220 | 0.36 ~ 0.09 | 20 / 34 / 38 / 40 | 0.3 | 98 | T8 18 / 20 / 36 / 40 T9 18 / 20 / 38 / 40 |
BM-UFL0581 | 110 / 220 | 0.54 ~0.27 | 58 | 0.45 | 99 | T8 58 PL 55 |
BM-EFL0381 | 220/277 | 0.19/0.15 | 41 | 0.36 | 99 | T8 38 |
BM-CFL0321 | 277 | 0.135 | 37 | 0.26 | 99 | T8 32 |
BM-CFL0401 | 277 | 0.15 | 40 | 0.31 | 99 | T8 36 / 40 T9 38 / 40 |
BM-CFL0581 | 277 | 0.22 | 61 | 0.5 | 99 | T8 58 |
Certified with CNS 13755 and registered for authentication by Bureau of Standards, Metrology and Inspection ,MOEA. CNS 14115 EMI specification compliant.
